Type 10
Free-running conveyor roller with plastic roller bearing, fitted with steel ball bearings. Suitable for transporting lightweight products on a gravity conveyor in a dry, dust-free environment. If the roller bearing is fitted with a dust-cap, this roller is also suitable for use in dusty environments.
| Material | Ppco-POM |
| Bearing | Steel-balls |
| Max-weight | 10 KG |
| Suitable for humid environments | No |
| Suitable for dusty environments | Yes |
| Color | Grey - Orange |
specifications
| Ø 8 | M 5 x 12 Internal thread Ø 8 x 10 Spring-loaded spindle sw 6 x 10 Spindle with flats Ø 8 x 10 Smooth spindle M 8 x 15 External thread met BD M 6 x 15Stepped spindle |
| Ø 10 | M 6 x 12 Internal thread Ø 10 x 10 Spring-loaded spindle sw 8 x 10 Spindle with flats Ø 10 x 10 Smooth spindle M 10 x 15 External thread met BD M 8 x 15Stepped spindle |
| zk 11 | sw 11 x 10 Spring-loaded spindle sw 11 x 10 Spindle with flats Ø 11 x 10 Smooth spindle |
| Ø 12 | M 6 x 12 Internal thread Ø 12 x 10 Spring-loaded spindle sw 10 x 10 Spindle with flats Ø 12 x 10 Smooth spindle M 12 x 15 External thread met BD M 10 x 15Stepped spindle |
| Steel Zinkplated | Ø 50 x 1.5 Ø 60 x 1.5 Ø 60 x 2.0 Ø 80 x 2.0 |
| Stainless steel | Ø 50 x 1.5 Ø 60 x 2.0 Ø 80 x 2.0 |
| PVC 5005 | Ø 50 x 2.8 Ø 63 x 3.0 Ø 90 x 7.0 |
| PVC 7011 | Ø 50 x 2.8 Ø 63 x 3.0 Ø 90 x 7.0 |
